Engineered for Demanding Industrial Applications
Ideal for:
✔ Semiconductor Inspection – Wafer defect detection, chip alignment
✔ Pharmaceutical Quality Control – Tablet imprint verification, packaging integrity
✔ Automotive Metrology – Dimensional analysis of precision components
✔ Aerospace Manufacturing – Composite material inspection, surface flaw detection
Key Advantages
✅ Full Frame Coverage
-
Supports 35mm sensors (44mm image circle)
-
Edge-to-edge sharpness with <1% vignetting
✅ Advanced Anti-Reflective Coating
-
Multi-layer broadband AR (400-900nm)
-
Reflectivity <0.3% at 550nm
✅ Ultra-Low Distortion
-
<0.05% barrel/pincushion distortion
-
Maintains measurement accuracy across entire FOV
✅ Industrial Robustness
-
Stainless steel barrel with IP54 rating
-
Thermal stable (-20°C to +60°C operation)
Technical Specifications
| Parameter | Specification |
|---|---|
| Focal Length | 35mm / 50mm / 90mm (custom available) |
| Aperture Range | f/2.0 – f/22 with clickless iris |
| Resolution | 120 lp/mm at >80% contrast |
| Working Distance | 200mm – ∞ |
| Sensor Compatibility | Full-frame CMOS/CCD (44mm image circle) |
| Mount Options | Canon EF, Nikon F, or custom OEM |
Special Features
-
Focus Lock Mechanism – Prevents drift in vibration environments
-
Modular Filter Thread – Accepts 52mm filters (ND, polarizers, etc.)
-
Coating Variants – Available in UV (250-400nm) or NIR (900-1600nm) optimized versions
Quality Assurance
-
Each unit includes:
-
Individual MTF test report
-
Calibration certificate
-
Environmental stress test data
-
-
Certifications:
-
ISO 9001:2015
-
RoHS/REACH compliant
-
