Technical Specifications
Optical Performance
-
Magnification: 0.5X-5X (software-assisted digital zoom to 10X)
-
Resolution: 8μm feature detection (supports 3000PPI displays)
-
Distortion: <0.1% TV distortion across entire FOV
-
Working Distance: 50-300mm (model dependent)
Mechanical Design
-
Housing: ESD-safe aluminum with anti-vibration mounts
-
Sensor Compatibility: 1″ to full-frame (44mm image circle)
-
Filter Thread: 62mm (standard)
-
Weight: 450g (typical configuration)
Special Features
-
Multi-Layer AR Coating: <0.5% reflectivity (400-650nm)
-
Polarization Options: Linear/circular polarizer variants
-
Coaxial Lighting Port: For integrated illumination
Industrial Applications
Display Manufacturing
-
OLED pixel defect detection
-
LCD mura effect analysis
-
Touch sensor pattern inspection
Quality Assurance
-
Smartphone/tablet display validation
-
Automotive panel inspection
-
AR/VR waveguide quality control
Emerging Technologies
-
MicroLED wafer inspection
-
Flexible display production
-
Transparent OLED verification
Included Components
-
Telecentric lens body
-
C-mount/TFL-II adapter set
-
Calibration target (USAF 1951)
-
Dust-proof storage case
Optional Accessories
-
UV enhancement kit (365nm inspection)
-
Automated focus adjustment module
-
Custom mounting brackets
Key Differentiators
-
Pixel-Perfect Imaging
-
Corrects field curvature at edges
-
Maintains <1% vignetting
-
-
Industrial Reliability
-
IP52 environmental protection
-
50,000+ cycle focus durability
-
Smart Factory Ready
-
Compatible with AI defect detection
-
Supports Industry 4.0 protocols
Quality Certification
-
ISO 9001:2015 certified production
-
IEC 61340-5-1 ESD compliance
-
Calibration traceable to NIST standards
